Indoor Vertical Mast Boom Lift

DXTT92-FB Self-propelled Vertical Mast Boom Lift

Our DAXLIFTER DXTT92-FB Self-propelled Vertical Mast Boom Lift is a compact electric aerial work platform featuring 11.2m maximum working height, 9.2m maximum platform height, 200kg loading capacity, 3m maximum horizontal reach and 7.89m up and over height, perfectly engineered for confined indoor commercial environments, warehouse maintenance, building fitting and facility inspection. This battery-powered man lift adopts vertical telescopic mast plus articulated boom design, with overall dimension 2.53m(L)×1.0m(W)×1.99m(H), compact body enables easy passage through standard doorways and narrow aisles. Equipped with 24V/240Ah battery, 24VDC/0.9kW drive motor and 24VDC/3kW lifting motor, the self-propelled vertical mast lift delivers stable performance; its travel speed reaches 4.5km/h when stowed and 0.5km/h at raised position, lifting time takes 42 seconds upward and 38 seconds downward.

Boasting ultra-small turning radius (0.23m inner turning radius, 1.65m outer turning radius), this electric vertical boom manlift provides superior flexibility for tight job sites. The platform dimension is 0.62m×0.87m×1.1m with 1.1m guardrail height. Ground clearance stands at 70mm under stowed status and 19mm when raised. Fitted with Φ381×127mm drive wheels, matched with 24V/30A built-in charger, the whole machine weighs 2950kg. Different from ordinary straight mast lifts, the articulated jib boom allows operators to bypass obstacles to reach hard-to-access overhead positions.

This MEWP aerial work platform is zero-emission, low-noise and rubber-wheel friendly to flooring, ideal for shopping malls, office buildings, exhibition halls, hotel maintenance, factory equipment installation and logistics warehouse servicing. Multiple built-in safety systems including tilt protection, overload limitation, emergency lowering function guarantee safe aerial operation. DAXLIFTER supplies CE certified vertical mast boom lift, support factory direct supply, OEM customization and after-sales technical guidance for global aerial equipment rental companies, engineering contractors and facility management enterprises.

Technical Data

Main Advantages

• Compact overall size, fit narrow indoor passages and standard door entry
• Articulated boom design, excellent over-and-up capability to bypass barriers
• Full electric battery drive, low noise, no exhaust, protect indoor floor surface
• Ultra-small turning radius, flexible steering inside workshops and buildings
• Complete safety protection devices: overload cut-off, tilt sensor, emergency descent
• Self-propelled driving function, can travel while platform is elevated
• Long endurance 24V battery pack, convenient built-in charger for daily charging

Application Scenarios

Indoor building maintenance, hotel & shopping mall decoration, exhibition venue setup, factory equipment installation, logistics warehouse overhead inspection, office building maintenance, airport terminal service, property facility management, aerial equipment rental fleet.
